Ggalaxy
Ggalaxy Series
GCL's Premier Fine-Pitch Indoor LED Display
The Ggalaxy Series represents GCL’s most refined approach to permanent indoor LED installations. Engineered for environments where image quality and long-term reliability are non-negotiable, the Ggalaxy delivers a visual experience that matches — and often surpasses — the demands of today’s most critical display applications.
7680Hz: The Refresh Rate That Matters When It Counts
A high refresh rate is often cited as a spec. On the Ggalaxy, it’s a practical differentiator. At 7680Hz, the display is fully camera-ready — no flicker, no rolling shutter artifacts, no banding in recorded or streamed content. For corporate image walls that regularly appear in conference backgrounds, or social content, this eliminates a persistent headache that lower-refresh-rate panels create.
Fine Pitch Options From P1.56 to P2.976
The Ggalaxy’s six pixel pitch configurations cover the full spectrum of fine-pitch indoor display needs, from ultra-close-range viewing in control rooms and broadcast studios (P1.56) to larger auditorium and conference installations where a slightly larger pitch delivers excellent image quality at a more accessible price point (P2.976).
The GOB-protected P1.56 and P1.953 models add a layer of physical durability that makes fine-pitch panels practical in spaces they’d otherwise be too delicate for — retail environments, hotel lobbies, and anywhere with regular foot traffic near the display surface.
For teams working in extended reality or virtual production, these LED panels are specifically tuned for camera-facing performance, minimizing the moiré and color fringing that can compromise on-camera image quality.
A Word on GOB Technology
Fine-pitch LED panels are inherently more vulnerable to physical contact — the smaller the pixel pitch, the more delicate the LED components. GOB (Glue-on-Board) encapsulation addresses this directly by sealing the LED surface in a transparent protective resin after assembly. The result is a panel that handles the daily realities of commercial environments — cleaning, accidental contact, humidity — without the fragility typically associated with sub-2mm pixel pitches. On the Ggalaxy P1.56 and P1.953 models, GOB is standard.
Who the Ggalaxy Series Is For
The Ggalaxy is the right choice for integrators and end users specifying a high-performance, fixed indoor LED wall in:
- Corporate headquarters and executive briefing centers — where the display is a centerpiece of how the organization presents itself
- Broadcast and television studios — where camera-readiness is mandatory, not optional
- Control rooms and command centers — where fine-pitch clarity and front-service access support continuous operation
- Hotel lobbies and hospitality venues — where GOB-protected panels hold up to high traffic without sacrificing image quality
- Retail and brand environments — where vibrant, seamless imagery drives engagement
Technical Parameter
| Product | P1.56 | P1.953 | P1.953 (XR) | P2.6 | P2.6 (XR) | P2.976 |
|---|---|---|---|---|---|---|
| Pixel Pitch | 1.5625mm | 1.953mm | 1.953mm | 2.604mm | 2.604mm | 2.976mm |
| Assembly Technology | GOB | GOB | GOB | / | / | / |
| LED Type | SMD1212 | SMD1212 | SMD1515 | SMD1515 | SMD1515 | SMD2020 |
| Brightness | 1000nits | 1200nits | 1200nits | 1200nits | 1200nits | 1200nits |
| Scan Rate | 1/20 | 1/16 | 1/8 | 1/16 | 1/8 | 1/21 |
| Refresh Rate | 7680HZ | 7680HZ | 7680HZ | 7680HZ | 7680HZ | 7680HZ |
| Panel Size | W19.7"xH19.7" (500x500mm) / W19.7"xH39.37" (500x1000mm available) | |||||
| Panel Resolution (Pixel) | 320x320 | 256x256 | 256x256 | 192x192 | 192x192 | 168x168 |
| Module Size | H9.85" xW9.85" | |||||
| Panel Material | Die-casting Aluminum | |||||
| Panel Weight | 17.6 lbs | |||||
| Protection Level | IP34 | |||||
| Maintenance | 100% Front and Rear Service | |||||
| Max Power Consumption | 143 watts | 143 watts | 158 watts | 143 watts | 158 watts | 143 watts |
| Average Power Consumption | 71.5 watts | 71.5 watts | 79 watts | 71.5 watts | 79 watts | 71.5 watts |
| Grey Scale | 16bit | |||||
| Viewing Angle | H160°, V160° | H1fil0 V140° | ||||
| Input Voltage | Wide Range 100-240VAC | |||||
| Working Temperature | -22°F to+ 149°F | |||||
| Working Humidity | 10%-90%RH | |||||
| Color Temperature | 6500-9500K | |||||
| Certifications | UL/EMC/CE/ROHS/CCC/FCC/ISO | |||||
Backed by GCL's Texas Operations
Every Ggalaxy panel shipped to North American customers comes out of GCL’s Dallas-area warehouse — inspected, tested, and ready to install. GCL has a physical U.S. facility and a locally staffed team, which means faster delivery, U.S.-based after-sales support, and a direct line to people who know the product.
For wholesale integrators and AV dealers, this removes the friction that comes with sourcing directly from overseas manufacturers — lead times, customs coordination, and support delays that add risk to project timelines.
